| General | |
| Status | Active |
| Watts | 7W |
| Incandescent Equivalent | 50W |
| Fluorescent Equivalent | 13W |
| Volts | 120V-277V |
| Ballast Type | Type B |
| Shape | T5 |
| Base | Miniature Bi Pin |
| ANSI Base | G5 |
| Nominal Length | 21 |
| Finish | Frost |
| CCT (Kelvin) | 3000K |
| Temperature | Warm White |
| CRI | 82 |
| Lumens | 700L |
| Beam Spread | 240 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | Linear |
| Lamp Type | Linear |
| Technology | LED |
| Electrical | |
| Watts | 7W |
| Incandescent Equivalent | 50W |
| Fluorescent Equivalent | 13W |
| Volts | 120V-277V |
| Ballasting Requirements | No ballast or external driver required |
| Ballast Type | Type B |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 3000K |
| Temperature | Warm White |
| CRI | 82 |
| Lumens | 700L |
| Beam Spread | 240 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| THD | 20% |
| Operating Temperature | -25C (-13F) to +45C (+113F) |
| Physical | |
| MOL | 20.91 |
| MOD | 0.83 |
| Nominal Length | 21 |
| Shape | T5 |
| Base | Miniature Bi Pin |
| ANSI Base | G5 |
| Finish | Frost |
| Material | Glass |
| Lens Finish | Frost |
| Weight (lb.) | 0.21 |
| Additional Information | |
| Additional Info | Replaces F13T5/WW lamps |
| Shatter-Proof Type | PET Coated |
| Installation Notes | Not for use in vapor tight fixtures. Direct wire 120-277V line voltage; Double ended wiring |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5 Year Limited - T5 LED Bulbs - Ballast Bypass |
| Compliance | |
| Safety Listing | cULus - Classified; cULus - Certified; ETLus - Sanitation Recognized Component |
| Location Rating | Damp |
| DLC Approved | No |
| DLC ID | FALSE |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| NSF Approved | Yes |
| SDS Sheet | LED Lamp |
| Packaging | |
| Each UPC | 045923119071 |
| Each Quantity | 1 |
| Each Length (in.) | 0.90 |
| Each Width (in.) | 0.90 |
| Each Height (in.) | 21.00 |
| Each Weight (lb.) | 0.13 |
| Each Cube (CuFt.) | 0.0098 |
| Pack Type | Box |
| Inner UPC | 20045923119075 |
| Inner Quantity | 10 |
| Inner Length (in.) | 2.80 |
| Inner Width (in.) | 5.30 |
| Inner Height (in.) | 23.00 |
| Inner Weight (lb.) | 1.30 |
| Inner Cube (CuFt.) | 0.1975 |
| Case UPC | 10045923119078 |
| Case Quantity | 100 |
| Case Length (in.) | 11.02 |
| Case Width (in.) | 12.60 |
| Case Height (in.) | 23.82 |
| Case Weight (lb.) | 13.39 |
| Case Cube (CuFt.) | 1.9140 |
5 Year Limited - T5 LED Bulbs - Ballast Bypass
