| Compliance | |
| UL Listed | Suitable for damp locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: S-HX3P9M |
| Performance | |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 250W Metal Halide |
| LED Characteristics | |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Consistency | 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED Color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Electrical | |
| Driver | Constant Current, Class 2, 480V, 50/60Hz, 480V: 0.20A |
| THD | 4.38% at 480V |
| Power Factor | 97% at 480V |
| Surge Protection | 6kV |
| Construction | |
| Cold Weather Starting | The minimum starting temperature is -20°C (-4°F) |
| Maximum Ambient Temperature | Suitable for use in up to 45°C (113°F) |
| Housing | Extruded aluminum |
| Lens | Polycarbonate lens |
| Reflector | Polyethylene Terephthalate (PET) |
| Installation | |
| Mounting | V hooks (chain by others) |
RAIL90/480
RAB Lighting
- SKU:
- RAIL90/480
- Availability:
- Usually ships within 1 week.
- Weight:
- 8.50 LBS
- Minimum Purchase:
- 1 unit
- Sell Sheet:
- Sell Sheet
- Spec Sheet:
- Spec Sheet
- Instructions:
- Instructions
- Watts:
- 90W
- Color Temp:
- 5000K (Cool)
- Lumens:
- 12,677 lm
- Efficacy:
- 145.7
- Color Accuracy:
- 83 CRI
- L70:
- 100,000 Hours
- Type:
- Constant Current
- Input Watts:
- 87W
