MASI20-200NW/D10

MASI20-200NW/D10

RAB Lighting

$810.00
(No reviews yet) Write a Review
SKU:
MASI20-200NW/D10
UPC:
19813307060
Availability:
Usually ships within 1 week.
Weight:
33.70 LBS
Shipping:
Calculated at Checkout
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
200W
Color Temp:
4000K (Neutral)
Lumens:
29,172 lm
Efficacy:
138
Color Accuracy:
72 CRI
L70:
100,000 Hours
Type:
Constant Current
V120:
1.76A
V208:
1.077A
V240:
0.933A
V277:
0.809A
Input Watts:
212.2W
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
200W
Color Temp:
4000K (Neutral)
Lumens:
29,172 lm
Efficacy:
138
Color Accuracy:
72 CRI
L70:
100,000 Hours
Type:
Constant Current
V120:
1.76A
V208:
1.077A
V240:
0.933A
V277:
0.809A
Input Watts:
212.2W
Adding to cart… The item has been added
Compliance
UL ListedSuitable for wet locations
IP RatingIngress protection rating of IP66 for dust and water
IESNA LM-79 & LM-80 TestingRAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC ListedThis product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: PK95K1W7
Optical
BUG RatingB4 U0 G2
Construction
Maximum Ambient TemperatureSuitable for use in up to 40°C (104°F)
Cold Weather StartingThe minimum starting temperature is -40°C (-40°F)
HousingDie-cast aluminum with stainless steel cover
GasketsHigh-temperature silicone gaskets
RetroplateAn optional retroplate allows for installation in openings from 4 to 6.5 inches in diameter. Additional retrofit options are available upon request to replace virtually any existing fixture. Please contact RAB Customer Service 1-888-722-1000.
FinishOur environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
Green TechnologyMercury and UV free. RoHS-compliant components.
Performance
Lifespan100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage EquivalencyEquivalent to 750W Metal Halide
LED Characteristics
LEDsLong-life, high-efficacy, surface-mount LEDs
Color Consistency7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color StabilityRAB LEDs exceed industry standards for chromatic stability
Color UniformityRAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Installation
MountingSemi-recessed construction. Junction box with four (4) 1/2" NPS conduit openings.
Electrical
DriverConstant Current, Class 2 100V - 277V, 50/60 Hz. THD <20%. PF >0.90, 450mA
Dimming DriverDriver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD4.7% at 120V, 11.7% at 277V
Power Factor99.9% at 120V, 94.4% at 277V
