| Compliance |
| UL Listed | Suitable for wet locations |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: P9Q89HB4 |
| Optical |
| BUG Rating | B2 U0 G1 |
| Construction |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Housing | Die-cast aluminum with stainless steel cover |
| Gaskets | High-temperature silicone gaskets |
| Retroplate | An optional retroplate allows for installation in openings from 4 to 6.5 inches in diameter. Additional retrofit options are available upon request to replace virtually any existing fixture. Please contact RAB Customer Service 1-888-722-1000. |
| Finish | Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 150W Metal Halide |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Consistency | 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | RAB LEDs exceed industry standards for chromatic stability |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Installation |
| Mounting | Semi-recessed construction. Junction box with four (4) 1/2" NPS conduit openings. |
| Electrical |
| Driver | Constant Current, Class 2 100V - 277V, 50/60 Hz. THD <20%. PF >0.90, 1400mA |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 6.6% at 120V, 7.8% at 277V |
| Power Factor | 99.2% at 120V, 96.5% at 277V |
