HID-70-EX39-840-BYP-ADJ

HID-70-EX39-840-BYP-ADJ

RAB Lighting

$144.03
(No reviews yet) Write a Review
SKU:
HID-70-EX39-840-BYP-ADJ
UPC:
19813908366
Availability:
Usually ships within 1 week.
Weight:
2.80 LBS
Shipping:
Calculated at Checkout
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
70W
Color Temp:
4000K
Lumens:
10,500 lm
Efficacy:
150
Color Accuracy:
80 CRI
L70:
50,000 Hours
Input Voltage:
100-277V
Power Factor:
>0.9
THDi:
<20%
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
70W
Color Temp:
4000K
Lumens:
10,500 lm
Efficacy:
150
Color Accuracy:
80 CRI
L70:
50,000 Hours
Input Voltage:
100-277V
Power Factor:
>0.9
THDi:
<20%
Adding to cart… The item has been added
Performance
Product TypeHID Replacement
Input Wattage70W
Lumens10,500lm
Efficacy150lm/W
L70 Lifespan50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency250W
DimmingCompatible with RAB specified 0-10V dimming system. Dimming capabilities were tested and verified on Legrand RH4FBL3PTC 0-10V dimming system.
LED Characteristics
Color Accuracy (CRI)80
Color Temperature4000K
Construction
Bulb ShapePost Top/ High Bay / Shoebox
Enclosure MaterialPolycarbonate & Metal heat sink
Housing FinishWhite
Installation
Base TypeEX39
Installation MethodUL Type B, Ballast Bypass
Burning PositionUniversal
Electrical
THD<20%
Power Factor>0.9
Input Voltage100-277V
Operating Frequency60 Hz
Operating Temperature-30°C to 60°C
Surge Protection4kV
Compliance
ListingsUL Listed, UL Classified
EnvironmentDamp / Enclosed
IP RatingIP64
RoHSMercury and UV free. RoHS-compliant components.
FCCComplies with Part 15B of the FCC Rules
Certification Model NumberH10026(HID-70-EX39-840-BYP-ADJ)
DLC ListedThis product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: PLNR6GZ59HS2
