| Compliance |
| UL Listed | Suitable for damp locations |
| DLC Listed | This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: PRKFYEK9 |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to (3) F32T8 |
| LED Characteristics |
| Color Stability | LED Color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Electrical |
| Driver | Constant current, Class 2, 120-277V, 50/60 Hz, 120V: 0.38A, 208V: 0.26A, 240V: 0.23A, 277V: 0.17A, 2kV surge protection |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 3.33% at 120V, 5.42% at 277V |
| Power Factor | 99.7% at 120V, 96.6% at 277V |
| Minimum Starting Temperature | 0° to 40°C |
| Construction |
| Housing | Die-formed 22 gauge, cold-rolled, post-painted steel. Post painting improves durability of the finish and eliminates the sharp edges making handling and installation safer. |
| Lens | Acrylic lens with diffusion for enhanced optical performance |
| Reflector | Aluminum with high-reflectance (91%) powder coat applied post production for a more durable finish |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Surface mount. Can be mounted with chains or v-hooks by others. |
