| Compliance |
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Electrical |
| Driver | Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.18A, 208V: 0.11A, 240V: 0.10A, 277V: 0.09A |
| Dimming Driver | 0 - 10V (at 120-277V), TRIAC and ELV (at 120V only) |
| THD | 12.1% at 120V, 21.9% at 277V |
| Power Factor | 98.5% at 120V, 88% at 277V |
| Optical |
| Optics | 80° |
| Performance |
| Lifespan | 50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -30°C (-22°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Lens | Solite Glass Lens and Microprismatic Diffusion Lens |
| Reflector | Vacuum-metalized polycarbonate |
| Housing | Extruded aluminum |
| Gaskets | High-temperature silicone |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Finish | Formulated for high durability and long-lasting color |
| Installation |
| Mounting | Wall direct light only |
