| Compliance | |
| UL Listed | Suitable for damp locations. Recommended for indoor use only. |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Construction | |
| IC Rated | Suitable for direct contact with insulation |
| Lens | High-transmission, microprismatic acrylic lens for smooth light distribution and uniformity |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Optical | |
| Reflector | 40° reflector |
| Aperture | 2.5" |
| LED Characteristics | |
| LEDs | Discrete LEDs on PCB board |
| Color Consistency | 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Performance | |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Electrical | |
| Drivers | 120 - 277V, 0 - 10V dimming down to 10%, 93.7% power factor, 1 kV surge protection |
BOA2LED-40YN
RAB Lighting
- SKU:
- BOA2LED-40YN
- UPC:
- 19813277233
- Availability:
- Usually ships within 1 week.
- Weight:
- 1.80 LBS
- Minimum Purchase:
- 1 unit
- Spec Sheet:
- Spec Sheet
- Instructions:
- Instructions
- Color Temp:
- 3500K (Warm Neutral)
- Color Accuracy:
- 82 CRI
- L70:
- 100,000 Hours
