| Compliance |
| UL Listed | Suitable for damp locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: PQDGXGOH |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| LED Characteristics |
| LEDs | Multi-chip, high-output, long-life LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Construction |
| Operating Temperature | -20°C (-4°F) to 50°C (122°F) |
| Housing | 22 gauge die formed with white powder coat finish. Y Hooks included for easy chain or cable mounting. |
| Reflector | White painted, reflective, die formed painted steel |
| Lens | Polycarbonate lens |
| Finish | Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Electrical |
| Driver | Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 0.81A, 208V: 0.48A, 240V: 0.41A, 277V: 0.36A |
| THD | 4.09% at 120V, 9.01% at 277V |
| Power Factor | 99.8% at 120V, 96.7% at 277V |
| Battery Backup | Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V. |
| Battery Backup Light Loss Factor | 0.25 |
| Surge Protection | 2.5kVFor areas prone to surges, upgrade to 10kV surge protection available |
| Installation |
| Mounting | V hooks and optional pendant mounting. AEROBAY® comes with two 42" chains. |
