| Compliance |
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| IP Rating | Ingress protection rating of IP65 for dust and water |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: PLM0Q6703U1F |
| Electrical |
| Driver | Constant Current, Class 2, 480V, 50/60Hz, 480V: 0.60A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 5.73% at 480V |
| Power Factor | 94.9% at 480V |
| Surge Protection | 10kV |
| 7-Pin Receptacle with Shorting Cap | ANSI C136.41 7-pin receptacle, compatible with wireless control systems |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Construction |
| IES Classification | The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area. |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Lens | Polycarbonate lens |
| Housing | Die-cast aluminum housing, lens frame and mounting arm |
| Vibration Rating | 3G vibration rating per ANSI C136.31 |
| EPA | 1 Fixture: 0.602 Fixtures at 90°: 0.772 Fixtures at 180°: 1.193 Fixtures at 90°: 1.194 Fixtures at 90°: 1.19EPA with Slipfitter & Adjustable Arm Mounting Accessories (Sold Separately)1 Fixture: 0.792 Fixtures at 90°: 0.972 Fixtures at 180°: 1.593 Fixtures at 90°: 1.594 Fixtures at 90°: 1.59 |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| LED Characteristics |
| LEDs | Long-life, high-efficiency, surface-mount LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Optical |
| BUG Rating | B4 U0 G4 |
| Installation |
| Mounting | Universal mounting arm compatible for hole spacing patterns from 1" to 5 1/2" center to center. Round Pole Adaptor plate included as a standard. Easy slide and lock to mount fixture with ease. Round pole diameter must be >4" to mount fixtures at 90° orientation. |
