Prizm Lighting LED-DR 30W
The LED-DR Series drivers feature universal 100-240V AC power input with exceptional reliability and class II rating. Standard built-in protections include short circuit, over-voltage, and overload protections. The LED-DR series is recommended to be used in non-dimming applications or when used to power secondary side dimming controls in low voltage LED fixture applications.
- 12V or 24V DC Constant voltage hardwire 30W LED driver
- Universal 100-240V AC input with built-in constant current limiting circuit
- Short circuit, over-load, and over temperature protections
- Operating temperature: -30~+50¡C
- Compact 94V-0 fire resistant plastic enclosure
- Class II / cRUus Recognized - Damp location rated
Series
LED-DR30
Input Voltage
100-240V AC
Output Voltage
12V DC / 24V DC
Max Load
30W
Minimum Load
6W
Dimmable
Non-Dimmable
Operating Temp
-22¡F to 122¡F (-30¡C to 50¡C)
Dimensions
6-1/4ÓL x 1-3/4ÓW x 1-3/16ÓH
Rating
cURus Recognized / Damp Location
PZM-LED-DR30-12Limited Quantities Available
LED-DR 30W / 12V DC Power Supply
PZM-LED-DR30-24
LED-DR 30W / 24V DC Power Supply
PZM-ENCL-11
Universal Metal Enclosure
