Features
¥ Narrow lightweight 2' and 4' aluminum body allows for optimal thermal management and ease of handling during installation
¥ Available with five different light distribution types: No lens, acrylic frosted general lens, acrylic frosted narrow lens, acrylic glare reduction lens, and acrylic clear focus lens
¥ Field installed or factory installed Battery Back Up available in 10w or 20w
¥ Field installed precision fit fixture wireguard available for 2' and 4' fixture lengths
¥ Rigid and suspended mounting options
¥ Single or bulk pack available
¥ More available, see factory and field installed fixture options
Electrical
¥ Available in 120v-277v, 347v and 480v
¥ Standard 0-10v dimming driver
¥ 6kV/3kA surge protection standard, 20kV/10kA surge protection available
¥ Power Factor > .90*
¥ Total Harmonic Distortion < 20%*
*Note: Varies based on option
Operating Range
¥ Varies depending on type. See data sheet for more information.
Control & Sensor Options
¥ Field or factory installed control and sensor options
¥ Manual programming sensors
¥ Remote programming sensors
¥ Onsite network programming
¥ Internet/Cloud based network programming
Certifications & Listings
¥ Buy American Act Compliant
¥ UL/cUL Listed
¥ UL Damp Listed
¥ DesignLights Consortium Standard qualified luminaire
¥ DesignLights Consortium Premium qualified luminaire
¥ Visit the DLC QPL for listed models
Rated Life
¥ Varies depending on type. See data sheet for more information.
