| Electrical |
| Drivers | Constant current, Class 2, 100 - 240VAC, 50 - 60 Hz, 0.18 Amps. |
| Photocell | 120V Swivel photocell included. Photocell is only compatible with 120V. |
| Surge Protection | 1 KV |
| Compliance |
| UL Listed | Suitable for wet locations in downlight position only. Suitable for mounting within 4ft (1.2m) of the ground. |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 13W CFL or 60W Incandescent |
| LED Characteristics |
| LEDs | 5W, high-output, long-life LED |
| Color Temperature | 5000K |
| Color Consistency | 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Construction |
| Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Thermal Management | Integral cast aluminum mounting pad for optimum heat sinking to ensure cool operation with maximum LED life and light output |
| Housing | Precision die-cast aluminum housing and mounting plate. 1 1/2" backbox with three 1/2" conduit entry points. |
| Gaskets | High-temperature silicone gaskets |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
