| Compliance |
| UL Listed | Suitable for wet locations |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| Title 24 Compliant | An IVEPARK edgelit garage fixture with a WS2 control option can be used to comply with 2016 Title 24 Part 6 Section 130.2 (a,b,c) |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Electrical |
| Driver | Class 2, 50/60Hz, 120-277V, 4kV standard, 10kV optional, 120V: 0.51A, 208V: 0.31A, 240V: 0.27A, 277V: 0.22A |
| THD | 5.95% at 120V, 2.87% at 277V |
| Power Factor | 99.5% at 120V, 97.55% at 277V |
| Battery Backup | Battery backup will operate the LED Lamp for 90 minutes if power fails. Wired for 120V-277V. |
| Battery Backup Light Loss Factor | 0.115 |
| Performance |
| Lifespan | Up to 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 250W Metal Halide |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -20°C (-4°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Lens | Diffused Polymethyl Methacrylate (PMMA) |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Surface mount standard (accessories available for wall, pole and trunnion mount) |
