| General | |
| Status | Active |
| Watts | 60W/80W/100W |
| Incandescent Equivalent | 250W/320W/400W |
| HID Equivalent | 175W/250W/320W |
| Volts | 100V-277V |
| Shape | Hi-Bay |
| Base | Mogul Extended |
| ANSI Base | EX39 |
| Finish | White |
| CCT (Kelvin) | 4000K |
| Temperature | Cool White |
| CRI | 80 |
| Lumens | 8400L/11220L/14000L |
| Beam Spread | 120 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | LED HID |
| Lamp Type | LED HID |
| Technology | LED |
| Min Compartment Size | Length: 15.75 in. Width: 14.96 in. |
| Ballasting Requirements | Ballast Bypass |
| Electrical | |
| Watts | 60W/80W/100W |
| Incandescent Equivalent | 250W/320W/400W |
| HID Equivalent | 175W/250W/320W |
| Volts | 100V-277V |
| Ballasting Requirements | Ballast Bypass |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 4000K |
| Temperature | Cool White |
| CRI | 80 |
| Lumens | 8400L/11220L/14000L |
| Beam Spread | 120 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.99 |
| Hours Rated | 50000 |
| Operating Position | Universal |
| Surge Protection | Built-in surge protection - 4KV |
| Operating Temperature | -25C (-13F) to +50C (+122F) |
| Physical | |
| MOL | 9.13 |
| MOD | 5.51 |
| Shape | Hi-Bay |
| Base | Mogul Extended |
| ANSI Base | EX39 |
| Finish | White |
| Weight (lb.) | 2.68 |
| Additional Information | |
| Min Compartment Size | Length: 15.75 in. Width: 14.96 in. |
| Rated For Enclosed Fixture | Yes |
| IP Rating | IP64 |
| Installation Notes | Not for use in vapor tight fixtures. |
| Warranty | 5 Year Limited - Hi-Pro |
| Compliance | |
| Safety Listing | cULus - Certified; cULus - Classified; cULus - Listed |
| Location Rating | Damp |
| DLC Approved | No |
| DLC ID | FALSE |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| SDS Sheet | LED Lamp |
| Packaging | |
| Each UPC | 045923331121 |
| Each Quantity | 1 |
| Each Length (in.) | 5.91 |
| Each Width (in.) | 5.91 |
| Each Height (in.) | 11.14 |
| Each Weight (lb.) | 2.91 |
| Each Cube (CuFt.) | 0.2252 |
| Pack Type | Box |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923331128 |
| Case Quantity | 6 |
| Case Length (in.) | 18.31 |
| Case Width (in.) | 12.40 |
| Case Height (in.) | 11.93 |
| Case Weight (lb.) | 22.70 |
| Case Cube (CuFt.) | 1.5675 |
5 Year Limited - Hi-Pro
