| Field Adjustability |
| Field Adjustable | Field Adjustable Light Output:
2 ft: 22W/17W/11W (factory default 22W)Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K) |
| Compliance |
| UL Listed | Suitable for damp locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Trade Agreements Act Compliant | This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act |
| DLC Listed | This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: S-IWJQ5M |
| Electrical |
| Driver | 20W: Class 1, Constant Current, 120-277V, 50/60 Hz, 120V: 0.17A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A
15W: Class 1, Constant Current, 120-277V, 50/60 Hz, 120V: 0.13A, 208V: 0.07A, 240V: 0.07A, 277V: 0.06A
10W: Class 1, Constant Current, 120-277V, 50/60 Hz, 120V: 0.08A, 208V: 0.06A, 240V: 0.05A, 277V: 0.04A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 7% at 120V, 7% at 277V |
| Power Factor | 99.5% at 120V, 97.3% at 277V |
| Surge Protection | L-N: 2KVL/N-GND: 4KV |
| Battery Backup | Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V. |
| Battery Backup Light Loss Factor | 20% |
| Performance |
| Lifespan | 50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| LED Characteristics |
| LEDs | Long-life, high-efficiency, surface-mount LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Construction |
| Cold Weather Starting | The minimum starting temperature is 0°C (32°F) |
| Maximum Ambient Temperature | Suitable for use in up to 50°C (122°F) |
| Housing | Sheet metal stamping 24 gauge, cold-rolled steel |
| Reflector | Sheet metal forming 24 gauge, cold-rolled steel with white powder coat |
| Lens | Diffused Polymethyl Methacrylate (PMMA) |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Surface mount. Can be mounted with v-hooks (ordered separately). |
| Sensor Settings |
| Operating Voltage | DC Input: 10.5-15VCurrent>50mA |
| Operating Temperature | Ta: -31° F (-35° C)* ~ +122° F(+50° C) |
| Sensor Warranty | 5-year sensor warranty |
| Sensitivity Setting | 25%/50%/75%/100% |
| Standby Period | 0s/10s/30s/1min/5min/10min/30min/60min/+∞ |
| Daylight | 2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable |
| Hold Time | 5s/30s/1min/3min/5min/10min/20min/30min |
| Standby Dimming | 10%/20%/30%/50% |
| Detection Angle | 30° to 150° without glass cover |
| Detection Distance | Radius 9.84-22.96ft(3-7m) |
| Mounting Height | Max 49ft.(15m) |
