Key Features:
End to End Connections
Link up to 360W (no Triac dimmer) or 120W (with Triac dimmer) using double ended connector included to make end to end connections. Optional interconnect wire available in 6in, 12in, or 36in.
Selectable CCT and Wattage
Choose your CCT and Wattage upon install; great for SKU reduction and job site flexibility. Choose between 5 CCT options (27/30/35/40/5000K) to compliment any environment.
Installation Made Easy
Surface mount brackets included, with magnetic mount brackets available as an accessory.
Highlights:
- Low profile solution for any cove or undercabinet project
- Linkable double ended connector included to make end to end connections
- Surface mounting hardware included
- Frosted polycarbonate lens eliminates glare
- On/Off switch available on each model except 3W
- T5 shape for retrofit applications
- LS2-JB, LS3-JBS or LS3-PC6 required to power LS3 fixtures. Sold Separately
- PowerSet feature allows for multiple lumen stops out of the box
- FieldCCeT features provides five color temperature settings in one fixture
Certifications:
- ETL listed for US & Canada
- RoHS Compliant
- FCC Compliant
- Damp Location
- IK08
Thermal:
- -4Deg. F to 104Deg. F (-20Deg. C to 40Deg. C) ambient operating temperature
Construction:
- White powder coated aluminum housing
- Impact-resistant polycarbonate lens
Applications:
- Cove
- Undercabinet
Specification:
- Voltage: 120VAC
- Lumens (lm): 1980/1650/1320 lm
- Wattage: 18/15/12W
- Efficacy (lm/W): 110 lm/W
- CCT (K): 2700K / 3000K / 3500K / 4000K / 5000K
- CRI: 80+
- Dimming: Triac
- Nominal Size: 47in
- Replacement for: 46in 28W T5 HE
- T20 Status: Exempt
- IP Rating: IP20
- Wet/Damp/Dry Location: Dry
- IK Rating: 8
- RoHS Compliant: Yes
- Dimensions (L x W x H): 46 1/4in x 1in x 1 3/8in (1175*25.5*35.5mm)
- Housing Color: White
- Lens Material New: Polycarbonate (PC)
- Ambient Temp Range: -13F to 113F (-25C to 45C)
5 Years
