Key Features:
Toolless Entry
Squeezing the sides together allows for the lens and LED board to be quickly removed, making wiring and installation easier.
Mounting Options
V-Hook and chain kit accessory available for suspension installation. Includes J-box cover plate. Optional aircraft cable accessory available and optional alignment plate to make row mounting connections easy (available for both surface and suspension mounting).
Controls Ready
Add controls anytime without the need for additional wiring. Remove the cap, then snap-in the standalone or networked lighting control solution.
Highlights:
- Unique toolless entry allows for the lens and LED board to be easily removed, allowing quick access to driver, simply squeeze the sides together for access
- Controls Ready makes adding controls quick and easy. Includes snap-in receptacle for Standalone (Sept 23) and Networked Lighting Controls
- 2 x 1/2in knockouts on each end
- Linear alignment plate accessory makes row mounting quick and easy
- V-Hook and chain kit accessory available for suspension mounting
- Junction box cover plate included
- PowerSet feature allows for multiple lumen stops out of the box
- FieldCCeT features provides multiple color temperature settings in one fixture
Certifications:
- UL listed for US & Canada
- RoHS Compliant
- FCC Compliant
- ICES-005 Compliant
- Damp Location rated
- DesignLights Consortium Premium Qualified - meets the requirements for the highest DLC qualification for efficacy and lumen maintenance- Pending
Thermal:
- -4Deg. F to 122Deg. F (-20Deg. C to 50Deg. C) ambient operating temperature
- Ambient operating temperature with sensor
Construction:
- White powder coated steel housing
- IK07 Rated non-yellowing PMMA light diffusing acrylic lens
Applications:
- Warehouses
- Manufacturing Plants
- Distribution Centers
- Grocery Stores
- Indoor Recreational Facilities
- Big Box Retail
- Service Repair Centers
Specification:
- Voltage: 120-347VAC
- Lumens (lm): 8,450/7,800/7,150 lm
- Wattage: 65/60/55W
- Efficacy (lm/W): 130 lm/W
- CCT (K): 3500K / 4000K / 5000K
- CRI: 80+
- Dimming: 0-10
- Nominal Size: 4ft
- Replacement for: 3 lamp 32W T8
- IP Rating: IP20
- Wet/Damp/Dry Location: Damp
- Dimensions (L x W x H): L: 47 5/16in (1202mm), W: 2 13/16in (72mm), H: 2 1/2in (64mm)
- Housing Color: White
- Lens Material New: Acrylic (PMMA)
- Ambient Temp Range: -4F to 122F (-20C to 50C)
- Driver Surge Protection (kV) new: L/N-PE: 2.5kV, L-N: 2.5kV
- Auxiliary Output: 12V, 100mA
5 Years
