| Compliance |
| UL Listed | Suitable for damp locations |
| CCEA Compliant | Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Trade Agreements Act Compliant | This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act |
| DLC Listed | This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: P38BFTBB |
| Performance |
| Lifespan | 60,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to (4)F32T8 or (4)F28T5 |
| Electrical |
| Driver | Constant Current, Class 2, 50/60 Hz, 120-277V, 120V: 0.34A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 8.34% at 120V, 5.94% at 277V |
| Power Factor | 99.2% at 120V, 94.9% at 277V |
| Battery Backup | Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V. |
| Battery Backup Light Loss Factor | 0.33 |
| Construction |
| IC Rated | Suitable for insulated ceilings |
| Maximum Ambient Temperature | Suitable for use in up to -30°C (-22°F) to 50°C(122°F) |
| Lens | Frosted polystyrene |
| Housing | Lightweight aluminum housing, steel pan and junction box |
| Installation | Standard integral T-bar clips secure the fixture to T-bars and prevent T-system separation |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Installation |
| Mounting | Recessed ceiling |
