| General | |
| Status | Active |
| Fixture Type | Flush Mount |
| Finish | Bronze |
| Wattage | 9W |
| Lumen Output | 650L-680L |
| CCT (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Indoor or Outdoor Fixture | Indoor |
| Specifications | |
| Technology | LED |
| Wattage | 9W |
| Lumen Output | 650L-680L |
| CCT (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Color Temperature | Warm White to Natural Light |
| CRI | 90 |
| Voltage | 120V |
| Beam Angle | 100 |
| Rated Hours | 50000 |
| Operating Temperature | -20C (-4F) to +40C (+104F) |
| Dimmable | Yes-Dimmable |
| Dimming Note | 120V only |
| Lens Material | Poly methyl methacrylate (PMMA) |
| Surge Protection | Built-in surge protection - 2.5KV |
| Weight (lb.) | 0.59 |
| Material | Die-Cast Aluminum |
| Dimensions | |
| Height (in.) | 0.67 |
| Width (in.) | 5 |
| Compliance | |
| Safety Listing | cETLus - Listed |
| Location Rating | Wet |
| Energy Star | Yes |
| ES Unique ID | ESID-3553074 |
| DLC Approved | No |
| Title 20 / 24 Status | California T24 Listed |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| NEC Compliance | Clothes Closet Certified - Reg: 410.16 (A)(3) and 410.16 (C)(5) |
| FCC Compliant | Yes |
| Flicker Free | No |
| SDS Sheet | LED Fixture |
| Additional Information | |
| Additional Information | UGR - 28.89; SDCM - 464; Hi pot - DC-1550V; Edge-lit - Yes |
| Specification Note | Overall height of fixture and driver: 1.59" |
| Installation Notes | Surface mount; Compatible with 3"&4" J-box and pancake J-box with additional accessory |
| Warranty | 5 Year Limited - Fixtures |
| Packaging | |
| Each UPC | 045923624964 |
| Each Quantity | 1 |
| Each Length (in.) | 5.20 |
| Each Width (in.) | 1.81 |
| Each Height (in.) | 5.20 |
| Each Weight (lb.) | 0.59 |
| Each Cube (CuFt.) | 0.0283 |
| Pack Type | Box |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923624961 |
| Case Quantity | 12 |
| Case Length (in.) | 11.81 |
| Case Width (in.) | 11.02 |
| Case Height (in.) | 5.91 |
| Case Weight (lb.) | 8.94 |
| Case Cube (CuFt.) | 0.4451 |
5 Year Limited - Fixtures
