| Compliance |
| UL Listed | Suitable for wet locations. Suitable for mounting within 4 ft of the ground. |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 250W Pulse Start Metal Halide |
| Construction |
| IES Classification | The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area. |
| Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Thermal Management | Cast aluminum Thermal Management system for optimal heat sinking. The ALED is designed for cool operation, most efficient output and maximum LED life by minimizing LED junction temperature. |
| Housing | Precision die-cast aluminum housing, lens frame |
| Arm | Die-cast aluminum with wiring access plate |
| Reflector | Specular vacuum-metallized polycarbonate |
| Gaskets | High-temperature silicone |
| EPA | 1 Fixture: 1.52 Fixtures at 90°: 2.42 Fixtures at 180°: 2.93 Fixtures at 90°: 3.24 Fixtures at 90°: 3.2 |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| LED Characteristics |
| LEDs | Two (2) multi-chip, high-output, long-life LEDs |
| Color Consistency | 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Electrical |
| Driver | Constant Current, 720mA, Class 2, 100 - 277V, 50 - 60 Hz, 100 - 277VAC .8 Amps. |
| THD | 13.33% at 120V |
| Power Factor | 99.2% at 120V, 97.3% at 277V |
| Surge Protection | 6kV |
| Optical |
| BUG Rating | B1 U1 G1 |
