| Field Adjustability |
| Field Adjustable (Wattage) | Field adjustable light output in 3 discrete steps:
Medium Housing: 150W/90W/78W (factory default 150W) |
| Compliance |
| UL Listed | Suitable for wet locations |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Trade Agreements Act Compliant | This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: S-4MLOS8 |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, discrete, surface-mount LEDs |
| Color Consistency | 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017. |
| Electrical |
| Driver | 78W: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.65A, 208V: 0.38A, 240V: 0.33A, 277V: 0.29A90W: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.75A, 208V: 0.44A, 240V: 0.38A, 277V: 0.33A150W: Constant Current, Non-Class 2, 120-277V, 50/60 Hz, 120V: 1.25A, 208V: 0.73A, 240V: 0.63A, 277V: 0.55A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 3.45% at 120V, 8.26% at 277V |
| Power Factor | 100% at 120V, 95.6% at 277V |
| Surge Protection | Line to Line: 10kVLine to Ground: 6kV |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 400W Metal Halide |
| Construction |
| IES Classification | The Type IV distribution is especially suited for mounting on the sides of buildings and walls, and for illuminating the perimeter of parking areas. It produces a semicircular distribution with essentially the same candlepower at lateral angles from 90° to 270°. |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Ambient Temperature | Max Power Temp Rating: 40°C (104°F)Middle Power Temp Rating: 52°C (125°F)Low Power Temp Rating: 54°C (130°F) |
| Housing | Die-cast aluminum |
| Lens | Polycarbonate lens |
| Reflector | Aluminum reflector with white polycarbonate |
| Vibration Rating | 3G vibration rating per ANSI C136.31 |
| Effective Projected Area | 1 Fixture: 0.37
2 Fixtures at 90°: 0.59
2 Fixtures at 180°: 0.74
3 Fixtures at 90°: 0.96
4 Fixtures at 90°: 0.96 |
| Gaskets | High-temperature silicone gaskets |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Universal mounting arm compatible for hole spacing patterns from 1" to 3" center to center. Round Pole Adaptor plate included as a standard. Easy slide and lock to mount fixture with ease. |
| Optical |
| Bug Rating | 150W: B2 U0 G490W: B1 U0 G378W: B1 U0 G3 |
