Leviton N3603 60 Amp, 600 Volt, Toggle In Type 3R Enclosure Three-Pole AC Manual Motor Controller, Industrial Grade, Grounded To Enclosure, Front Wired, - Gray

Leviton N3603 60 Amp, 600 Volt, Toggle In Type 3R Enclosure Three-Pole AC Manual Motor Controller, Industrial Grade, Grounded To Enclosure, Front Wired, - Gray

Leviton

(No reviews yet) Write a Review
SKU:
LEVITON-N3603
Weight:
0.00 LBS
Call for price
Leviton N3603 60 Amp, 600 Volt, Toggle In Type 3R Enclosure Three-Pole AC Manual Motor Controller, Industrial Grade, Grounded To Enclosure, Front Wired, - Gray

60 Amp, 600 Volt, Toggle In Type 3R Enclosure Three-Pole AC Manual Motor Controller, Industrial Grade, Grounded To Enclosure, Front Wired, - Gray

Powerswitch¨ Industrial Grade AC Manual Motor Controllers provide safe, reliable control of a variety of motor loads. Typical applications include manual ON/OFF switching control of conveyor systems, pumping machines, HVAC systems, air compressors and other heavy manufacturing equipment. These motor controllers are available for both single-phase and three-phase applications.



AC Horsepower Ratings
HP Rating: 10HP-240V 25HP-480V 30HP-600V

Electrical Specifications
Amperage: 60 A
Dielectric Voltage: Withstands 2200V for 1 min.
Endurance: 6,000 cycles inductive motor type load
Grounding: Non-Grounding
Pole: 3
Temperature Rise: 50¼C Max at full rated current
Voltage: 600 VAC

Environmental Specifications
Enclosure Rating: Type 3R
Flammability: Rated V-0 per UL 94
Operating Temperature: -40¡C to 60¡C

Material Specifications
Base Material: Thermoplastic Polyester
Color: Grey
Contacts: .046" Thick Silver-Cadmium Oxide
Enclosure Material: Powder-Coated Steel
Face Material: Thermoplastic Polyester
Handle Material: Valox 357 PBT
Strap Material: Nickel Plated Brass
Terminal Screws: Zinc-Plated Steel, Triple Combination
Toggle: Thermoplastic Polyester
Yoke: Nickel-Plated Brass

Mechanical Specifications
Product ID: Ratings are permenantly marked on device
Terminal Accom.: 10-4 AWG
Terminal ID: T1, T2, T3, L1, L2 & L3 marked on back of device
Termination: Front
Torque Range: 25 inch pounds maximum

Product Features
Color: Grey
Device Type: Enclosed Switch

Standards and Certifications
ANSI: C-73
NEMA: WD-1 & WD-6
NOM: NOM-ANCE
UL 60947-4-1: supersedes UL 508
Warranty: 10-Year Limited
cUL per CSA C22.2 No. 111: File #E63969


AC Horsepower Ratings
HP Rating: 10HP-240V 25HP-480V 30HP-600V

Electrical Specifications
Amperage: 60 A
Dielectric Voltage: Withstands 2200V for 1 min.
Endurance: 6,000 cycles inductive motor type load
Grounding: Non-Grounding
Pole: 3
Temperature Rise: 50¼C Max at full rated current
Voltage: 600 VAC

Environmental Specifications
Enclosure Rating: Type 3R
Flammability: Rated V-0 per UL 94
Operating Temperature: -40¡C to 60¡C

Material Specifications
Base Material: Thermoplastic Polyester
Color: Grey
Contacts: .046" Thick Silver-Cadmium Oxide
Enclosure Material: Powder-Coated Steel
Face Material: Thermoplastic Polyester
Handle Material: Valox 357 PBT
Strap Material: Nickel Plated Brass
Terminal Screws: Zinc-Plated Steel, Triple Combination
Toggle: Thermoplastic Polyester
Yoke: Nickel-Plated Brass

Mechanical Specifications
Product ID: Ratings are permenantly marked on device
Terminal Accom.: 10-4 AWG
Terminal ID: T1, T2, T3, L1, L2 & L3 marked on back of device
Termination: Front
Torque Range: 25 inch pounds maximum

Product Features
Color: Grey
Device Type: Enclosed Switch

Standards and Certifications
ANSI: C-73
NEMA: WD-1 & WD-6
NOM: NOM-ANCE
UL 60947-4-1: supersedes UL 508
Warranty: 10-Year Limited
cUL per CSA C22.2 No. 111: File #E63969
